Ring Graph Animation ¶

Ring Graph Animation¶

This example demonstrates how to use Matplotlib’s animation features in order to animate a ring graph sequentially being revealed.

import igraph as ig
import matplotlib.pyplot as plt

# Animate a directed ring graph
g = ig.Graph.Ring(10, directed=True)

# Make 2D ring layout
layout = g.layout_circle()

# Create canvas
fig, ax = plt.subplots()
ax.set_aspect(1)

# Prepare interactive backend for autoupdate
plt.ion()
plt.show()

# Animate, one vertex at a time
for frame in range(11):
    # Remove plot elements from the previous frame
    ax.clear()

    # Fix limits (unless you want a zoom-out effect)
    ax.set_xlim(-1.5, 1.5)
    ax.set_ylim(-1.5, 1.5)

    # Plot subgraph
    gd = g.subgraph(range(frame))
    ig.plot(gd, target=ax, layout=layout[:frame], vertex_color="yellow")

    # matplotlib animation infrastructure
    fig.canvas.draw_idle()
    fig.canvas.start_event_loop(0.5)

The received output is:

The visualisation of a animated ring graph — Sequentially Animated Ring Graph¶

Note

We use igraph’s Graph.subgraph() (see induced_subgraph()) in order to obtain a section of the ring graph at a time for each frame.
